Description
Manufacturer OEM Number:
PEUGEOT : 19209V
Replace part numbers:
ACI - AVESA : AMP-064
CONTINENTAL/VDO : A97110
MAGNETI MARELLI : 230016079227
MAGNETI MARELLI : B30/00
MAGNETI MARELLI : B30/01
Warranty: 3 Years
Application:
PEUGEOT 206 Hatchback (2A/C) 1.1 i 1998-2007 HFX (TU1JP),HFZ (TU1JP) 1124 44 Hatchback
PEUGEOT 206 SW (2E/K) 1.1 2002-2007 HFX (TU1JP) 1124 44 Estate
TECHNICAL PARAMETER:
Operateing Temperature Range:-40℃-125℃(150℃ peak)
Nominal Operating Voltage:12VDC
MIN/MAX Operating Voltage:7.5V-14VDC
Resistance Per Winding (@25℃):53Ω±10%
Minimum Resistance (@-40℃):35Ω
Solenoid inductance:33mH±20%
Step Increment :0.04167mm
MAX travel:8.5mm(204step)
