Description
Manufacturer OEM Number:
90120 390120 F01R065901 53030657
53009735 53030450 53030657AB
Replaces dealer part numbersr:
53030450 53030657 53030657AB 53030657AC AC68 CV10155 5003467AA
21821 217204 217-204 IAC34 53009735 17119277 AC305 IAC34 2H1091
Features:
1. Long lasting and reliable working life time
2. OEM quality
3.100% Tested Before leaving factory
Warranty:1 Years
Aplication:
-
for QQ F3 473QE six -generation V19
-
-
-
Technical Parameter:
Oeperateing Temperature Range:-40℃-125℃(150℃ peak)
Nominal Operating Voltage:12VDC
MIN/MAX Operating Voltage:7.5V-14VDC
Resistance Per Winding (@25℃):53Ω±10%
Minimum Resistance (@-40℃):35Ω
Solenoid inductance:33mH±20%
Step Increment :0.04167mm
MAX travel:8.5mm(204step)
-
Payment:
We accept Alipay, West Union, TT. All major credit cards are accepted through secure payment processor ESCROW.
Shippings:
1. Worldwide shipping. (Except some countries and APO/FPO).
2. Orders processed timely after the payment verification.
3.more details can contact us.
Returns:
We offer not less than 30 days for return and refund policies. If you receive the items have quality problems or damaged,
pleaseprovided the photos and contact us, we will resend it or refund your payment. But we will not accept return by
buyer operationalerrors caused damaged items.
