Description
Manufacturer OEM Number:
59600 17059600 92026922 92062155 A95163 AT-59600R C0273 C0273 ICD00126 AC64
Warranty: 3 Years
Application:
Chinese Brand
ChangHe 1.0L
HaFei Song Hua Jiang 1.0L
ChangAn Auto 1.6L
Chevrolet
BLAZER S10 2.2 L43 2198CC 84KW 4Cylinder 1994-2005
BLAZER S10 2.2 B 22 NZ 2198CC 83KW 4Cylinder 1995-1998
IPANEMA 1.8 1796CC 72KW 4Cylinder 1989-1999
IPANEMA 1.8 alcool 1798CC 73KW 4Cylinder 1991-1997
IPANEMA 1.8 Hybrid 1796CC 73KW 4Cylinder 1991-1999
IPANEMA 2.0 1998CC 85KW 4Cylinder 1991-1997
IPANEMA 2.0 1998CC 81KW 4Cylinder 1991-1997
IPANEMA 2.0 alcool 1998CC 85KW 4Cylinder 1991-1997
KADETT 1.8 1796CC 72KW 4Cylinder 1991-1999
KADETT 1.8 alcool 1798CC 73KW 4Cylinder 1991-1997
KADETT 2.0 1998CC 81KW 4Cylinder 1989-1997
KADETT 2.0 1998CC 85KW 4Cylinder 1991-1997
KADETT 2.0 alcool 1998CC 85KW 4Cylinder 1991-1997
MONZA 1.8 1796CC 73KW 4Cylinder 1984-1995
MONZA 1.8 alcool 1796CC 73KW 4Cylinder 1991-1995
MONZA 2.0 1988CC 81KW 4Cylinder 1991-1996
MONZA 2.0 alcool 1988CC 85KW 4Cylinder 1991-1996
MONZA 2.0 alcool 1988CC 85KW 4Cylinder 1989-1991
S10 Pickup 2.2 B 22 NZ 2198CC 83KW 4Cylinder 1995-1998
TECHNICAL PARAMETER:
Operateing Temperature Range:-40℃-125℃(150℃ peak)
Nominal Operating Voltage:12VDC
MIN/MAX Operating Voltage:7.5V-14VDC
Resistance Per Winding (@25℃):53Ω±10%
Minimum Resistance (@-40℃):35Ω
Solenoid inductance:33mH±20%
Step Increment :0.04167mm
MAX travel:8.5mm(204step)
