Description
Manufacturer OEM Number:
AT-02001R 46451794 40415202 219244820500 B20/01
Features:
1. Long lasting and reliable working life time
2. OEM quality
3.100% Tested Before leaving factory
Warranty:1 Years
Aplication:
FOR Alfa Romeo
145 930 1.4 i.e. 1994/07-1996/12 1351 ccm, 66 KW, 90 PS
145 930 1.6 i.e. 1994/10-1996/12 1596 ccm, 76 KW, 103 PS
146 930 1.4 i.e. 1994/12-1996/12 1351 ccm, 66 KW, 90 PS
146 930 1.6 i.e. 1994/12-1996/12 1596 ccm, 76 KW, 103 PS
FOR Fiat
Brava 182 1.6 16V 1995/10-2001/10 1581 ccm, 66 KW, 90 PS
Brava 182 1.6 16V 1996/02-2001/10 1581 ccm, 76 KW, 103 PS
Bravo I 182 1.6 16V 1995/10-2001/10 1581 ccm, 66 KW, 90 PS
Bravo I 182 1.6 16V 1996/03-2001/10 1581 ccm, 76 KW, 103 PS
Marea 185 1.6 100 16V 1996/09-2002/05 1581 ccm, 76 KW, 103 PS
Marea Weekend 185 1.6 100 16V 1996/09-2002/05 1581 ccm, 76 KW, 103 PS
Palio Weekend 178DX 1.6 16V 1996/04-2001/02 1581 ccm, 74 KW, 100 PS
Tempra 159 1.8 i.e. 1993/09-1996/08 1756 ccm, 76 KW, 103 PS
Tempra 159 1.8 i.e. 1993/09-1996/08 1756 ccm, 66 KW, 90 PS
Tempra 159 1.8 i.e. 1994/10-1996/08 1756 ccm, 74 KW, 101 PS
Tempra S.W. 159 1.8 i.e. 1993/09-1996/08 1756 ccm, 76 KW, 103 PS
Tempra S.W. 159 1.8 i.e. 1993/09-1996/08 1756 ccm, 66 KW, 90 PS
Tempra S.W. 159 1.8 i.e. 1994/10-1996/08 1756 ccm, 74 KW, 101 PS
Tipo 160 1.8 i.e. 1993/04-1995/04 1756 ccm, 76 KW, 103 PS
Tipo 160 1.8 i.e. 1993/09-1995/04 1756 ccm, 66 KW, 90 PS
FOR Lancia
Delta II 836 1.6 i.e. 1996/03-1999/08 1581 ccm, 66 KW, 90 PS
Delta II 836 1.6 i.e. 16V 1996/01-1999/08 1581 ccm, 76 KW, 103 PS
Delta II 836 1.8 i.e. 1993/06-1999/08 1756 ccm, 76 KW, 103 PS
Delta II 836 1.8 i.e. 1994/07-1999/08 1756 ccm, 66 KW, 90 PS
Technical Parameter:
Oeperateing Temperature Range:-40℃-125℃(150℃ peak)
Nominal Operating Voltage:12VDC
MIN/MAX Operating Voltage:7.5V-14VDC
Resistance Per Winding (@25℃):53Ω±10%
Minimum Resistance (@-40℃):35Ω
Solenoid inductance:33mH±20%
Step Increment :0.04167mm
MAX travel:8.5mm(204step)
You can always CONTACT US with your car details so we can find the part required
