Description
Manufacturer OEM Number:
91296 20327 61296
Features:
1. Long lasting and reliable working life time
2. LOREADA Original OEM
3. 100% Tested Before leaving factory
Warranty:1 Years
Application:
FOR BYD F3 F3R L3 G3 473QE 465QA
FOR Chery QQ7083 (371 engines)
FOR DODGE RAIDER/RAM 50/SPIRIT/STEALTH
FOR HYUNDAI:SONATA
FOR MITSUBISHI:3000GT/DIAMANTE/MIGHTA MAX
FOR FORD:MONTERO
Technical Parameter:
Operating Temperature Range:-40℃-125℃(150℃ peak)
Nominal Operating Voltage:12VDC
MIN/MAX Operating Voltage:7.5V-14VDC
Resistance Per Winding (@25℃):53Ω±10%
Minimum Resistance (@-40℃):35Ω
Solenoid inductance:33mH±20%
Step Increment :0.04167mm
MAX travel:8.5mm(204step)
