Description
Manufacturer OEM Number:
B28/00
C95177
7701042784
FDB1513
230016079207
556014
6NW009141-421
7701047909
B3355
D95174
Warranty: 3 Years
Application:
For RENAULT
For MEGANE I (BA0/1_) 1.6 e (BA0F, BA0S) 1598 66 4 Hatchback 1996-1999
For MEGANE I (BA0/1_) 1.6 i (BA0L) 1598 55 4 Hatchback 1996-1999
For MEGANE I Cabriolet (EA0/1_) 1.6 e (EA0F) 1598 66 4 Convertible 1996-1999
For MEGANE I Classic (LA0/1_) 1.6 e (LA0F, LA0S) 1598 66 4 Saloon 1996-1999
For MEGANE I Classic (LA0/1_) 1.6 i (LA0L) 1598 55 4 Saloon 1996-1999
For MEGANE I Coach (DA0/1_) 1.6 e (DA0F) 1598 66 4 Coupe 1996-1999
For MEGANE I Grandtour (KA0/1_) 1.6 e (KA0F) 1598 66 4 Estate 1999-2003
For MEGANE Scenic (JA0/1_) 1.6 e (JA0F) 1598 66 4 MPV 1996-1999
For MEGANE Scenic (JA0/1_) 1.6 i (JA0L) 1598 55 4 MPV 1997-1999
TECHNICAL PARAMETER:
Operateing Temperature Range:-40℃-125℃(150℃ peak)
Nominal Operating Voltage:12VDC
MIN/MAX Operating Voltage:7.5V-14VDC
Resistance Per Winding (@25℃):53Ω±10%
Minimum Resistance (@-40℃):35Ω
Solenoid inductance:33mH±20%
Step Increment :0.04167mm
MAX travel:8.5mm(204step)
