Description
Manufacturer OEM Number:
93744875
17102851 93744675 17059603 C2177
Warranty: 3 Years
Application:
for Buick Chevrolet Optra/Lacetti 2007-2012
TECHNICAL PARAMETER:
Operateing Temperature Range:-40℃-125℃(150℃ peak)
Nominal Operating Voltage:12VDC
MIN/MAX Operating Voltage:7.5V-14VDC
Resistance Per Winding (@25℃):53Ω±10%
Minimum Resistance (@-40℃):35Ω
Solenoid inductance:33mH±20%
Step Increment :0.04167mm
MAX travel:8.5mm(204step)
