Description
Manufacturer OEM Number:
35150-22600 AC4229
Warranty: 1 Years
Application:
US Market
For HYUNDAI ACCENT II (LC) 1.5 G4EB 1495CC 66KW Hatchback 2000-2005
For HYUNDAI ACCENT II (LC) 1.5 G4EC-G 1495CC 75KW Hatchback 2000-2005
For HYUNDAI ACCENT II (LC) 1.6 G4ED-G 1599CC 77KW Hatchback 2002-2005
For HYUNDAI ACCENT Saloon (LC) 1.5 G4FK 1495CC 75KW Saloon 1999-2002
For HYUNDAI ACCENT Saloon (LC) 1.5 G4EB 1495CC 66KW Saloon 2000-2005
For HYUNDAI ACCENT Saloon (LC) 1.6 G4ED-G 1599CC 77KW Saloon 2002-2005
For HYUNDAI COUPE (GK) 2.0 G4GC-G 1975CC 100KW Coupe 2001-2009
For HYUNDAI ELANTRA (XD) 1.8 G4BB 1795CC 97KW Hatchback 2000-2006
For HYUNDAI ELANTRA (XD) 2.0 G4GC-G 1975CC 102KW Hatchback 2000-2006
For HYUNDAI ELANTRA (XD) 2.0 G4GC 1975CC 104KW Hatchback 2000-2006
For HYUNDAI ELANTRA Saloon (XD) 1.8 G4BB 1795CC 97KW Saloon 2000-2006
For HYUNDAI ELANTRA Saloon (XD) 2.0 G4EC-G 1975CC 102KW Saloon 2000-2006
For HYUNDAI ELANTRA Saloon (XD) 2.0 G4GC 1975CC 104KW Saloon 2000-2006
For HYUNDAI GETZ (TB) 1.3 i G4E-A 1341CC 60KW Hatchback 2002-2004
For HYUNDAI GETZ (TB) 1.5 CRDi D3-EA 1493CC 60KW Hatchback 2003-2005
For HYUNDAI GETZ (TB) 1.5 i G4ER 1495CC 73KW Hatchback 2003-2005
For HYUNDAI MATRIX (FC) 1.8 G4GB-G 1795CC 90KW MPV 2001-2010
For KIA CERATO (LD) 1.6 G4ED 1599CC 77KW Hatchback 2004-
For KIA CERATO Saloon (LD) 1.6 G4ED 1599CC 77KW Saloon 2004-
EU Market
For 2000-2002 HYUNDAI ACCENT 1.5L SOHC L4 12V, ENG.CODE "ALPHA G4EB"
For 2001-2005 HYUNDAI ACCENT 1.6L DOHC L4 16V, ENG.CODE "ALPHA G4ED"
For 2007-2009 HYUNDAI ELANTRA 2.0L DOHC L4 16V, ENG.CODE "BETA II G4JP"
For 2003 HYUNDAI TIBURON 2.0L DOHC L4 16V, ENG.CODE "BETA G4GF"
TECHNICAL PARAMETER:
Operateing Temperature Range:-40℃-125℃(150℃ peak)
Nominal Operating Voltage:12VDC
MIN/MAX Operating Voltage:7.5V-14VDC
Resistance Per Winding (@25℃):53Ω±10%
Minimum Resistance (@-40℃):35Ω
Solenoid inductance:33mH±20%
Step Increment :0.04167mm
MAX travel:8.5mm(204step)
