Description
OEM / Part Number:
38 38 DGEV
38 38 DGES 390 CFM
38DGAS
38 DGAS
32 36 DGAV
32 36 DGEV
Warranty:
1 Year Guarantee.
Application:
For Fiat/Ford/VolksWagen/Renault/Dodge/Toyota/Jeep/BMW/Mitsubishi/Daewoo
Replace for VW Rabbit Scirocco Golf 1600cc 1800cc - 8 Valve, Except Cross Flow.
Replace for 1976-1980 Dodge Arrow Sedan/Pickup,
Replace for 1984-1990 Caravan,
Replace for 1976-1983 Challenger Sapporo, 79-ON D50 Pickup 2.0 and 2.6 Engines.
Replace for Mazda B2600 1987-1993 & All Mitsubishi Montero 2.6L Engine.
Replacement for the Holley 5200 carburetor
Replacement for the Fiat 124 131
Attention:
The 32/36 DFEV carburetor can be found in multiple conversion kits offered by FOR VW Beetle, FOR VW Rabbit, A/T versions for the 2.6 Mitsubishi engines, and FIAT applications are most common
The Empi version uses all Weber parts; gaskets, jets, etc.
This is the 32/36 DFEV model, which features an electric choke.
The electric chokes are far more efficient than the water chokes that FOR Fiat used originally.
This carburetor will provide a performance upgrade over most of the original Fiat models.
Specifications:
Primary Venturi: φ26mm
Secondary Venturi;φ10.5mm
Primary Auxiliary Venturi; φ27mm
Secondary Auxiliary Venturi;φ10.5mm
Primary Main Jet;1.37mm
Secondary Main Jet; 1.4mm
Primary Air Corrector Jet;1.6mm
Secondary Air Corrector Jet :1.65mm
Primary Emulsion Tube; F66
Secondary Emulsion Tube; F50
Primary idle Jet;0.6mm
Secondary Idle Jet; 0.5mm
Pump Jet;φ0.55mm
Needle Valve; 2.0mm
Float Measurement :47mm
