Description
Manufacturer OEM Number:
817253, 817255, 17112023, 17112031
Other Part Number:
A95214, 17059603, 59603, 817253, 817255, 17112023, 17112031
Warranty: 3 Years
TECHNICAL PARAMETER:
Oeperateing Temperature Range:-40℃-125℃(150℃ peak)
Nominal Operating Voltage:12VDC
MIN/MAX Operating Voltage:7.5V-14VDC
Resistance Per Winding (@25℃):53Ω±10%
Minimum Resistance (@-40℃):35Ω
Solenoid inductance:33mH±20%
Step Increment :0.04167mm
MAX travel:8.5mm(204step)
Application:
For VAUXHALL OPEL ASCONA C;
For OPEL ASTRA F;
For OPEL ASTRA F Cabriolet/Kombi/Schraqheck/Van ;
For OPEL KADETT E;
For OPEL KADETT E Cabriolet/Kombi/Schraqheck
