Description
Manufacturer OEM Number:
078133455D
407501520
D95109
6NW 009 141-461
Warranty: 3 Years
Application:
for AUDI 80 (8C, B4) (1991/09 - 1994/12)
for AUDI 80 Avant (8C, B4) (1991/09 - 1996/01)
for AUDI COUPE (89, 8B) (1988/10 - 1996/12)
for AUDI A4 (8D2, B5) (1994/11 - 2001/09)
for AUDI A6 (4A, C4) (1994/06 - 1997/10)
for AUDI CABRIOLET (8G7, B4) (1991/05 - 2000/08)
for AUDI A6 Avant (4A, C4) (1994/06 - 1997/12)
for AUDI A4 Avant (8D5, B5) (1994/11 - 2001/09)
TECHNICAL PARAMETER:
Operateing Temperature Range:-40℃-125℃(150℃ peak)
Nominal Operating Voltage:12VDC
MIN/MAX Operating Voltage:7.5V-14VDC
Resistance Per Winding (@25℃):53Ω±10%
Minimum Resistance (@-40℃):35Ω
Solenoid inductance:33mH±20%
Step Increment :0.04167mm
MAX travel:8.5mm(204step)
