Description
Manufacturer OEM Number:
026906247
40439102
B34/01
F00099M102
026 906 247
Warranty: 3 Years
Application:
For VOLKSWAGEN GOL 1.6 BWX 1596CC 73KW Hatchback 1998-2008
For VOLKSWAGEN GOL 1.6 BWX 1596CC 71KW Hatchback 2003-2008
For VOLKSWAGEN GOL 1.6 Flex BWX BJF 1595CC 73KW Hatchback 2003-2008
For VOLKSWAGEN GOL 1.8 BNY 1781CC 72KW Hatchback 1994-2003
For VOLKSWAGEN GOL 1.8 UDH UDB 1781CC 72KW Hatchback 1994-2003
For VOLKSWAGEN PARATI 1.6 BJF BWX 1588CC 60KW Estate 1982-1995
For VOLKSWAGEN PARATI 1.8 UDH UDB 1781CC 72KW Estate 1999-2005
For VOLKSWAGEN PARATI 1.8 BNY 1781CC 73KW Estate 2002-
For VOLKSWAGEN POINTER Variant 1.8 UDH 1781CC 73KW Estate 2002-2006
For VOLKSWAGEN SAVEIRO Platform/Chassis 1.6 Flex BJF BWX 1595CC 73KW Platform/Chassis 2003-2009
For VOLKSWAGEN SAVEIRO Platform/Chassis 1.8 UDH 1781CC 72KW Platform/Chassis 2000-2005
For VOLKSWAGEN SAVEIRO Platform/Chassis 1.8 Flex BNY 1781CC 78KW Platform/Chassis 2005-2009
TECHNICAL PARAMETER:
Operateing Temperature Range:-40℃-125℃(150℃ peak)
Nominal Operating Voltage:12VDC
MIN/MAX Operating Voltage:7.5V-14VDC
Resistance Per Winding (@25℃):53Ω±10%
Minimum Resistance (@-40℃):35Ω
Solenoid inductance:33mH±20%
Step Increment :0.04167mm
MAX travel:8.5mm(204step)
